Functional sheet
Sheet in which a coating is applied to a general sheet, and an additional function with printing, etc. is added. It can be selected for a wide variety of applications such as architecture/civil engineering, and industry.
Features
- Weather resistance, abrasive resistance, heat insulation, and designability, etc.
- CARBOGLASS™SG(W) and CARBOGLASS™SG-AH can be used in custom-made products
- Excellent in shock resistance
- It has a feature in which the flame goes out when moved away from a flame source, and there is less concern over toxic gas compared to plastics
- Operating temperature has a wide range from -40℃ to +125℃
- Products with the certification DW-9054 are also available
- Easy to process (i.e. cutting, drilling)
- Specific gravity 1.2 (specific gravity of CARBOGLASS™CFR110C is 1.32)
Product list
| Brand | Product name | Color | Features |
|---|---|---|---|
| CARBOGLASS™ | XL frost pattern | Clear | High weather resistance sheet on one surface (matte on one surface) |
| CARBOGLASS™ | XLW | 4 colors | High weather resistance sheet on both surfaces |
| CARBOGLASS™ | High weather resistance sheet on both surfaces | ||
| CARBOGLASS™ | SGW frost pattern | Clear | High weather resistance sheet on both surfaces (matte on one surface) |
| CARBOGLASS™ | SG-AH | Clear | Abrasive resistance/Weather resistance sheet (coating on one surface/both surfaces) |
| CARBOGLASS™ | Antistatic sheet on both surfaces (polish on both surfaces) | ||
| CARBOGLASS™ | DEFR | Light opal/Opal | Diffusion/Nonbromine-/Nonphosphorus-based flame-retardant sheet |
| CARBOGLASS™ | PURE EFR | Clear | Nonbromine-/Nonphosphorus-based flame retardant sheet |
- Since March 1, 2014, sales of LEXAN SG305 and MARGARD have been transferred to SABIC Innovative Plastics Japan Ltd.
CARBOGLASS™ XLW
Clear
Polycarbonate sheet with high weather resistance coating applied on both surfaces so as to prevent yellowing/deterioration, and maintain the original transparency for a long time. It excels in appearance, and there is hardly any distortion on the surface specific to the high weather resistance sheet.
